SPECIFICATIONS
Pitch: 2.54
Poles: 2～20
Applicable wire: AWG＃28～＃22
Voltage rating : 250V DC/AC（rms）
Current rating: 3.0A
Withstand voltage: 1500V AC（rms）
Working Temperature: -25℃～+ 85℃
Insulation resistance: ≥1000MΩ
Contact resistance: ≤0.02Ω

MATERIAL
Housing: NYlon66 UL94V-0
Water: NYlon66 UL94V-0
Terminal: Phosphor bronze
