SPECIFICATIONS
Pitch: 3.96
Poles: 2～16
Applicable wire: AWG＃24～＃18
Voltage rating : 250V DC/AC（rms）
Current rating: 5.0A
Withstand voltage: 1500V AC（rms）
Working Temperature: -25℃～+ 85℃
Insulation resistance: ≥1000MΩ
Contact resistance: ≤0.02Ω

MATERIAL
Housing: NYlon66 UL94V-2
Pin header: NYlon66 UL94V-2
Terminal: Phosphor bronze
