SPECIFICATIONS
Poles:17、27
Voltage rating (MAX): 50V DC/AC (rms)
Current rating: 0.2A
Working Temperature: -20℃～+ 85℃

Withstand voltage: 250V AC (r ms)
Insulation resistance: 500M Ω
Contact resistance: ODD CKTS ≤0.08Ω
                EVEN CKTS ≤0.04Ω
Single Contact

MATERIAL
Contact : Phosphor Bronze Tin-plated
Solder tab : Phosphor Bronze Tin-plated
Housing : Heat resistance plastic (UL94V-0)
Slider : Heat resistance plastic (UL94V-0)

PACKAGE
Tape and Reel Package
Pipe Package
Bag Package
