SPECIFICATIONS
Poles: 4～50
Voltage rating : AC,DC,50V(RMS)
Current rating: 0.5A
Withstand voltage: 200V AC/rms
Working Temperature: -20℃～+ 85℃
Insulation resistance: ≥500M Ω
Contact resistance: ≤0.03Ω
Single Contact

MATERIAL
contact: Phosphor Bronze Tin-plated

Solder  tab:phosphor Bronze tin-plated
HOUSING
Material: Nylon46, UL94V-0
Slider:Heat resistance plastic(UL94V-0)

PACKAGE
TAPE AND REEL PACKAGE
PIPE PACKAGE
BAG PACKAGE
