Technical parameters:
Pitch: 2.0
Number of lines: 2 ~ 16
Applicable wire gauge: AWG# 30 ~ # 24
Rated voltage: 250V DC/AC (RMS)
Rated current: 2.0A
Voltage: 800V AC (RMS)
Operating temperature: -25℃ ~ +85℃
Insulation resistance: ≥1000MΩ
Contact resistance: ≤0.02Ω
Applicable printed board thickness: 0.8mm ~ 1.6mm

Material:
Housing: Nylon 66 UL94V-0
Needle base:
1. Base: Nylon 66 UL94V-0
2. Pin: Brass
Terminal: phosphor bronze
